The mini BNC-50KY RF connector is a miniaturized, highly compatible standard 50Ω RF connecting device. It inherits the classic BNC bayonet quick-connect structure and is optimized for miniaturization, specially designed for low-loss and high-stability signal transmission of miniaturized RF equipment. Selected high-quality materials are adopted for the product, combined with micro precision processing technology, featuring excellent weather resistance and compact structure. It perfectly meets the RF signal connection requirements in various fields such as small communication terminals, portable test instruments and micro security modules. As an optimal connection solution for the R&D of miniaturized RF system equipment, production of portable products and supporting of precision modules, it provides stable and reliable signal connection guarantee for all kinds of micro RF applications.
Core Materials
🟠 Contact parts: High-conductivity brass (with gold plating), improving the conductivity and corrosion resistance of micro contact points and ensuring the stability of signal transmission.
🟠 Insulating parts: Polytetrafluoroethylene (PTFE), featuring high temperature resistance and excellent dielectric properties, suitable for high-frequency miniaturized signal transmission scenarios.
🟠 Housing/structural parts: High-quality brass (HPB59-1), with nickel plating, the micro structure is tough and wear-resistant, enhancing the overall mechanical strength.
| Item | Specification |
|---|---|
| Characteristic impedance | 50Ω |
| Frequency range | DC~6GHz |
| Insulation resistance | ≥5000MΩ |
| Dielectric withstanding voltage | ≥1000V (AC RMS) |
| Mechanical Performance | / |
| Connection method | Micro bayonet quick connection, adapted to the operating space of small equipment with convenient mating and unplugging |
| Mechanical life | ≥500 mating cycles |
| Environmental Performance | / |
| Operating temperature | -45℃~+125℃, adapted to extreme high and low temperature environments, meeting the outdoor use requirements of portable equipment |
| Compliance and Minimum Order Quantity | / |
| Compliance | Conforms to the RoHS 2.0 international standard and environmental protection requirements |
| Minimum order quantity | ≥100PCS |
🟠 Miniaturization & Low Loss: The micro precision structural design combined with gold-plated contact parts effectively reduces signal transmission loss and contact resistance while achieving miniaturization, reduces electromagnetic interference, and ensures high-fidelity transmission of RF signals within 6GHz, perfectly adapting to miniaturized and high-precision RF application scenarios.
🟠 Durable Micro Structure: The housing and structural parts adopt the brass nickel-plating process, and the contact parts are gold-plated, with strong corrosion and wear resistance. The micro contact points bear force evenly, which can withstand multiple mating cycles and frequent disassembly and assembly of small equipment, prolonging the product service life and reducing replacement costs.
🟠 Convenient Bayonet Connection: The optimized micro bayonet quick-connect structure is adapted to the narrow operating space of small equipment. Mating, unplugging and locking can be completed quickly by hand without professional tools, with a firm and non-loosening connection, which greatly improves the installation, commissioning and maintenance efficiency of small equipment and precision modules.
🟠 Wide Temperature & Weather Resistance for Universal Adaptation: It can work stably in an extreme temperature range of -45℃ to +125℃, resistant to vibration, salt spray and dust, and is adapted to harsh service environments such as portable outdoor equipment, micro security sites and industrial small measurement and control terminals.
🟠 Small Communication Systems: Suitable for portable mobile communication terminals, micro RF modules, wireless Bluetooth RF components, private network small communication equipment, etc., realizing the efficient transmission of RF signals between miniaturized equipment and modules, and ensuring the stability of communication links.
🟠 Portable Test and Measurement: Serving as the RF signal interface of small test instruments such as handheld oscilloscopes, mini signal generators and portable spectrum analyzers, meeting the high-precision signal testing requirements of on-site detection, outdoor testing and mobile laboratories.
🟠 Micro Security Monitoring: Applied to micro high-definition surveillance cameras, portable video transmission equipment and small security RF transceivers, adapted to indoor concealed security and outdoor mobile security scenarios, ensuring the stable transmission of video and RF signals.
🟠 Small Industrial Electronics: Adapted to industrial micro automation equipment, small Radio Frequency Identification (RFID) readers, portable microwave detection equipment and industrial small measurement and control terminals, it can withstand complex working conditions such as vibration, high and low temperatures in industrial sites, and adapt to the installation requirements of small industrial equipment.
🟠 RF Supporting for Consumer Electronics: Used in the consumer electronics field such as small UAV RF modules, smart wearable device RF components and vehicle-mounted micro RF terminals, meeting the RF connection requirements of miniaturization and portability of consumer electronics.
Q: What is the lead time for custom mini BNC-50KY RF connectors?
A: The lead time is usually 1 to 2 weeks, depending on the complexity of custom requirements (such as special surface treatment, non-standard dimensions) and the scale of the purchase order. The delivery date for bulk customization can be coordinated according to the production plan.
Q: What core performance improvements do gold-plated contact parts bring to the mini BNC-50KY micro connector?
A: Aiming at the characteristics of small contact points and easy oxidation of micro connectors, the contact parts are gold-plated. The gold layer has excellent conductivity, oxidation resistance and corrosion resistance, which can effectively reduce the contact resistance of micro contact points and improve signal transmission efficiency. At the same time, it prolongs the mating service life of the connector, adapting to the use requirements of small equipment in harsh service environments such as heavy dust, high humidity and salt spray.
Q: Do your company provide installation and technical support for the mini BNC-50KY RF connector?
A: We mainly supply high-performance RF connector products, and at the same time can provide professional technical support including installation guidance, cable adaptation suggestions, on-site technical consultation, etc., to ensure the correct installation and stable use of the connectors.
Ready to choose a more reliable connection solution for your RF system? Contact us today to get free technical consultation and exclusive quotation for the mini BNC-50KY RF connector. Our team of RF technical experts is ready to answer your questions and provide customized solutions for you.
E-mail: [email protected]
Tel: 86-18115599525
Transmit stable signals with precision connections —— mini BNC-50KY RF connector, escort your RF system!
