The MMCX-JWB2 RF connector is a compact, high-reliability standard RF connecting device, specially designed for low-loss, high-frequency signal transmission in miniaturized RF equipment. Integrating miniaturized design, high-quality material selection and precision processing technology, the product features excellent vibration resistance and environmental adaptability. It can meet the mini RF signal connection requirements in various fields such as wireless communication, consumer electronics, test and measurement, and the Internet of Things (IoT). Whether for the research and development of portable devices, high-density module integration or the manufacturing of miniaturized terminals, it is an ideal choice for signal connection in micro RF systems, providing stable and efficient connection guarantee for various miniaturized RF applications.
Core Materials
🟠 Contact parts: High-conductivity brass (with gold plating), enhancing high-frequency conductivity and anti-plugging wear resistance.
🟠 Insulators: Modified polytetrafluoroethylene (PTFE), featuring excellent high-frequency dielectric properties, high temperature resistance and low loss.
| Item | Specification |
|---|---|
| Characteristic impedance | 50Ω (standard RF impedance) |
| Frequency range | DC~6GHz |
| Insulation resistance | ≥1000MΩ |
| Dielectric withstanding voltage | ≥1000V (AC RMS) |
| Contact resistance | Outer conductor ＜2.5mΩ, inner conductor ＜5mΩ |
| Mechanical Performance | / |
| Mechanical life | ≥500 mating cycles |
| Axial retention force | ≥10N |
| Environmental Performance | / |
| Operating temperature | -55℃~+165℃, suitable for the high and low temperature operating environment of small equipment |
| Compliance and Minimum Order Quantity | / |
| Compliance | Conforms to the RoHS 2.0 international environmental protection standard |
| Minimum Order Quantity (MOQ) | ≥100PC |
🟠 Ultra-miniaturized design: Adopting a micro structural layout, its volume is much smaller than traditional RF connectors, greatly improving equipment integration.
🟠 High-frequency and low-loss transmission: The combination of modified PTFE insulators and gold-plated high-conductivity contact parts effectively reduces the transmission loss and reflection of high-frequency signals, ensuring high-fidelity transmission of RF signals within 6GHz and meeting the needs of high-frequency communication, precision testing and other scenarios.
🟠 Excellent vibration and wear resistance: The contact parts are treated with hard gold plating and the shell with nickel plating, boasting strong resistance to plugging wear and corrosion. Meanwhile, it has outstanding vibration resistance, maintaining stable connection without signal interruption even when the equipment is in mobile or vibrating working conditions.
High compatibility and universality: The 50Ω standard RF impedance design is compatible with the full range of MMCX connectors and can be adapted to RF cables such as RG086 and RG405, meeting the diversified connection needs of miniaturized equipment.
🟠 High precision and stability in processing: Strict tolerance control of micro components, minimal mating clearance and a compact and firm structure effectively shield external electromagnetic interference, ensuring stable product performance without attenuation during long-term and high-frequency use, and adapting to the long-term and reliable operation needs of micro equipment.
🟠 Wireless communication: Suitable for Bluetooth headsets, wireless network cards, small wireless routers, RF modules, portable communication terminals, etc., realizing high-efficiency transmission of RF signals in miniaturized equipment and ensuring stable communication links.
🟠 Consumer electronics: Applied to portable smart devices such as smart watches, action cameras, tablet computers and UAVs, adapting to the miniaturization and lightweight design requirements of equipment and providing reliable RF signal connection.
🟠 Test and measurement: Served as the RF interface of miniaturized test instruments, RF test probes, handheld spectrum analyzers and other equipment, meeting the needs of high-precision signal testing in laboratories and on-site portable scenarios.
🟠 Internet of Things (IoT): Adapted to IoT sensing terminals, micro RFID devices, wireless data acquisition modules, etc., able to withstand slight outdoor vibration and high/low temperature environments, ensuring stable wireless signal transmission of IoT equipment.
🟠 Automotive electronics: Applied to on-board small RF equipment, on-board navigation, vehicle networking terminals, etc., utilizing its vibration resistance and wide temperature characteristics to adapt to the complex working conditions during vehicle operation.
Q: What is the lead time for customized MMCX-JWB2 RF connectors?
A: The lead time is usually 1 to 2 weeks, depending on the complexity of customized requirements (such as special surface treatment, non-standard dimensions) and the scale of purchase orders. The delivery date for bulk customization can be coordinated according to the production plan.
Q: Can the MMCX-JWB2 RF connector be used in the frequent movement of portable devices?
A: Yes. This product is specially designed for portable and mobile equipment, with excellent vibration resistance and axial retention force. It can maintain a tight connection without signal attenuation or interruption even when the equipment is in frequent movement, slight collision or vibrating working conditions.
Q: What cable specifications does the MMCX-JWB2 RF connector support, and is customized adaptation available?
A: The product is natively adapted to RF cables such as RG086 and RG405. Meanwhile, it can support customized cable adaptation specifications, pin lengths, etc. according to customers' actual needs, meeting the personalized connection needs of micro equipment.
Q: Does your company provide technical support and installation guidance for the MMCX-JWB2 RF connector?
A: We mainly supply high-performance RF connector products, and at the same time can provide professional technical support, including installation guidance, cable adaptation suggestions, on-site technical consulting, etc., to ensure the correct installation and stable use of the connector.
