Product Introduction of F-C-JW1.5 RF Connector

Specifications and Parameters

Core Materials

🟠 Contact parts: High-conductivity brass (with gold plating), enhancing electrical conductivity, oxidation resistance and corrosion resistance.

🟠 Insulating parts: Polytetrafluoroethylene (PTFE), featuring high temperature resistance and excellent dielectric properties, suitable for high-frequency RF signal transmission.

🟠 Housing/structural parts: High-quality brass (HPB59-1), with nickel plating, improving structural strength, wear resistance and shielding effect.

🟠 Sealing parts: High-quality silicone rubber, enhancing waterproof and dustproof performance, applicable to complex outdoor and industrial environments.

Electrical Performance

Product Features

🟠 Low loss and high stability: Gold-plated contact parts combined with a precise structural design greatly reduce contact resistance and signal transmission loss. Excellent shielding performance effectively reduces electromagnetic interference, ensuring high-fidelity transmission of RF signals within 3GHz, and is suitable for scenarios with high requirements for signal stability such as radio and television and satellite reception.

🟠 Extra-long mechanical life: The housing and structural parts adopt the brass nickel-plating process, and the contact parts are gold-plated, with outstanding corrosion resistance, wear resistance and anti-mating fatigue performance. Stable performance can be maintained after more than 500 mating cycles, greatly reducing the later replacement and maintenance costs.

🟠 Firm connection and anti-loosening:The threaded screw connection structure has better sealing and fastening performance compared with the snap-in connection, with no risk of loosening after screwing. It can adapt to vibration-prone application scenarios such as outdoor base stations and vehicle-mounted equipment, ensuring continuous signal transmission.

🟠 High protection and strong weather resistance: Achieves the IP65 protection grade in the screwed and locked state, combined with a wide operating temperature range of -40℃~+125℃. It is resistant to salt spray, rain, and sudden changes in high and low temperatures, and can work stably for a long time in harsh environments such as outdoor radio and television transmitting stations, satellite receiving terminals, and outdoor security points.

🟠 Precise craftsmanship and easy assembly: Strict dimensional tolerance control and surface treatment standards result in minimal fitting clearance between components and a stable structure; the screw tightening torque is moderate, allowing installation and disassembly by hand without professional tools, improving the efficiency of equipment installation, commissioning and maintenance.

🟠 Low MOQ and high flexibility: The minimum order quantity is as low as 100PCS, which not only supports bulk procurement for enterprise supporting production, but also adapts to the needs of engineering contractors for small-batch replenishment and laboratory sample testing, with higher procurement flexibility.

Application Scenarios

🟠 Radio and television communication field: Suitable for radio and television transmitting/receiving equipment, cable TV signal transmission links, radio and television optical receivers/transmitters, etc. It meets the core demand of the radio and television system for 75Ω impedance and low-loss signal transmission, ensuring clear and stable TV signals.

🟠 Satellite reception system: Serves as the RF signal interface of satellite antennas, set-top boxes and satellite receivers to realize the efficient transmission of satellite RF signals. It is suitable for household and commercial satellite reception scenarios, with strong anti-interference ability and more stable signal reception.

🟠 Security monitoring system: Applied to high-definition analog surveillance cameras, video optical transceivers and security RF transmission equipment, suitable for indoor and outdoor security points, especially the harsh working conditions of outdoor monitoring, ensuring long-distance and low-loss transmission of video RF signals.

🟠 Test and measurement field: As the RF interface of instruments such as RF signal generators, spectrum analyzers and TV signal testers, it meets the high-precision testing requirements of laboratories and inspection institutions for 75Ω impedance RF signals.

🟠 Civil communication equipment: Adapts to civil RF products such as satellite TV, cable TV household access equipment and household RF converters, with convenient installation and stable connection, improving the user experience of civil RF equipment.

🟠 Renovation and replacement projects: Can directly replace the same-specification F-series RF connectors in old radio and television, security and satellite reception equipment without modifying the original circuits and structures of the equipment, quickly improving the signal transmission performance of the equipment and reducing the overall upgrade and transformation costs.

🟠 Vehicle-mounted RF equipment: Adapts to vehicle-mounted RF products such as vehicle-mounted TV and vehicle-mounted satellite reception systems. The threaded anti-loosening design can resist vibration during vehicle driving, ensuring continuous and stable vehicle-mounted RF signals.

Frequently Asked Questions (FAQ)

Q: What is the lead time for custom F-C-JW1.5 RF connectors?
A: The lead time is usually 1 to 2 weeks, depending on the complexity of custom requirements (such as special surface treatment, non-standard dimensions) and the scale of the purchase order. The delivery date for bulk customization can be coordinated according to the production plan.

Q: Does your company provide technical support and installation guidance for the F-C-JW1.5 RF connector?
A: We mainly supply high-performance RF connector products, and at the same time can provide professional technical support, including installation guidance, cable adaptation suggestions, on-site technical consultation, etc., to ensure the correct installation and stable use of the connectors.

Q: Can the gold plating thickness of the F-C-JW1.5 RF connector be customized, and what impact do different thicknesses have on performance?
A: The product adopts the industry-standard gold plating thickness by default, and also supports customers' custom requirements for gold plating thickness; the thicker the gold plating layer, the stronger the oxidation resistance, corrosion resistance and wear resistance of the contact parts, and the mating life will also be correspondingly improved, making it more suitable for extreme harsh use environments such as high humidity, high salt spray and heavy dust.

Contact Us

Ready to choose a high-stability and high-compatibility connection solution for your RF system? Contact us today to get free technical consultation, sample testing and exclusive quotation for the F-C-JW1.5 RF connector. Our team of RF technical experts is ready to answer your questions and tailor an RF connection solution suitable for your scenarios.

E-mail: [email protected]
Tel: 86-18115599525
Transmit stable RF signals with precision threads —— F-C-JW1.5 RF connector, escort your RF system!
