Product Introduction of TNC-C-KY3 RF Connector

Specifications and Parameters

Core Materials

Contact parts: High-conductivity brass (gold-plated), enhancing electrical conductivity, oxidation resistance and corrosion resistance.

Insulators: Polytetrafluoroethylene (PTFE), high temperature resistant, low dielectric loss, suitable for high-frequency and high-speed signal transmission.

Housing/structural parts: High-quality brass (HPB59-1), nickel-plated, improving structural strength and wear resistance.

Seals: High-performance silicone rubber, enhancing the waterproof and dustproof protection level, suitable for complex and harsh working conditions.

Electrical Performance

Product Features

🟠 High-frequency, low-loss and high-fidelity: The optimized structural design combined with gold-plated high-conductivity contact parts effectively reduces signal transmission loss and contact resistance, with excellent electromagnetic shielding performance. It can ensure high-fidelity transmission of RF signals within 6GHz, suitable for high-end scenarios such as high-precision testing and high-frequency communication.

🟠 Vibration-resistant, anti-loosening and ultra-durable: No loosening after locking, with outstanding vibration and impact resistance; the housing and structural parts adopt brass nickel-plating process, and the contact parts are gold-plated, which have strong corrosion resistance, wear resistance and aging resistance, greatly extending the service life of the product.

🟠 Precise structure and good protection: Strict micron-level tolerance control, extremely small fitting gap between components, and strong structural stability.

🟠 Ultra-wide temperature full-domain adaptation: It can work stably in the ultra-wide temperature range of -65℃ to +165℃, resistant to high and low temperatures and temperature changes without performance attenuation, meeting the application scenarios with strict requirements on environmental adaptability.

🟠 High compatibility and strong adaptability: 50Ω standard RF impedance design, fully compatible with TNC series connectors of the same specification, and can be adapted to various mainstream RF cables such as RG58, RG142 and LMR240, meeting the connection needs of different equipment and different projects, with strong versatility and interchangeability.

🟠 Industrial-grade quality assurance: Strict quality inspection standards throughout the entire production process, multiple inspection procedures from raw material selection to finished product delivery, ensuring the consistency and stability of product performance, no performance attenuation during long-term continuous work, and providing continuous and reliable connection for RF systems.

Application Scenarios

🟠 Communication systems: Suitable for 5G/4G mobile communication base stations, microwave communication equipment, private network communication base stations, etc. It can resist the impact of strong vibration and temperature changes of outdoor base stations, and ensure long-distance and high-stability transmission of RF signals.

🟠 Military and aerospace supporting: Adapt to military electronic equipment, airborne RF modules, shipborne communication equipment, aerospace ground measurement and control equipment, etc., meeting the strict requirements of military-grade vibration resistance, wide temperature and high protection.

🟠 Test and measurement: As the RF signal interface of high-end test instruments such as oscilloscopes, signal generators, spectrum analyzers and network analyzers, it meets the high-precision and high-frequency signal testing needs of laboratories and testing institutions.

🟠 Industrial electronics: Applied to industrial automation measurement and control equipment, radio frequency identification (RFID) reading and writing equipment, microwave detection equipment, mine/oilfield industrial communication terminals, etc., it can withstand complex working conditions such as vibration, dust, high and low temperatures in industrial sites.

🟠 Security and radio and television: Suitable for high-definition security monitoring base stations, outdoor video transmission equipment, radio and television transmitting/receiving equipment, and radio and television signal trunk transmission links, ensuring the anti-interference and stability of signal transmission.

Frequently Asked Questions (FAQ)

Q: What is the delivery time for customized TNC-C-KY3 RF connectors?
A: The delivery time is usually 1 to 2 weeks, depending on the complexity of custom requirements (such as special surface treatment, non-standard dimensions) and the scale of the purchase order. The delivery date for bulk customization can be coordinated according to the production plan.

Q: What are the core advantages of the threaded connection of the TNC-C-KY3 RF connector compared with the bayonet type?
A: The core advantages of the threaded locking connection are anti-loosening and anti-vibration. The contact gap after locking is extremely small. Under working conditions with strong vibration and frequent movement (such as vehicle-mounted, airborne, and base station outdoor equipment), it can effectively avoid signal interruption or attenuation caused by loose connection, and at the same time improve the overall protection performance, which is more suitable for harsh industrial-grade and military-grade application scenarios.

Q: What cable specifications does the TNC-C-KY3 RF connector support, and can it be customized to adapt to special cables?
A: The product is conventionally adapted to various mainstream RF cables such as RG58, RG142 and LMR240; at the same time, it supports customization according to drawings according to customers' actual needs to meet personalized connection requirements.

Q: Does your company provide technical support and installation guidance for the TNC-C-KY3 RF connector?
A: We mainly supply high-performance RF connector products, and at the same time can provide professional technical support, including installation guidance, cable adaptation suggestions, on-site technical consultation, etc., to ensure the correct installation and stable use of the connector.

Contact Us

Are you ready to choose a more reliable connection solution for your RF system? Contact us today to get free technical consultation and exclusive customized quotation for the TNC-C-KY3 RF connector. Our team will tailor an RF connection solution suitable for different application scenarios for you, and escort your RF system throughout the whole process!

E-mail: [email protected]
Tel: 86-18115599525
Precise connection for stable signal transmission —— The TNC-C-KY3 RF connector escorts your RF system!
