Product Introduction of SMP-KWB2 RF Connector

Specifications and Parameters

Core Materials

🟠 Contact parts: High-purity oxygen-free brass (gold-plated, meeting 48H salt spray test), which greatly improves electrical conductivity, corrosion resistance and oxidation resistance.

🟠 Insulators: Polytetrafluoroethylene (PTFE), with low dielectric loss, high temperature resistance and excellent high-frequency characteristics, suitable for ultra-high-frequency signal transmission.

🟠 Housing/structural parts: High-quality brass (HPB59-1), with hard nickel plating treatment, enhancing structural strength, wear resistance and fatigue resistance.

Electrical Performance

Product Features

🟠 Ultra-miniature and high-frequency, suitable for high-density integration: Adopting SMP standard ultra-miniature structural design, it has a small volume and can realize high-density layout of RF modules. With an ultra-wide frequency range of DC~6GHz, it meets the high-frequency signal transmission needs of high-end fields such as microwave communication, radar and aerospace, and is the core connecting device of ultra-miniaturized RF systems.

🟠 Low loss and high fidelity, excellent signal transmission: Ultra-precise impedance matching design combined with high-purity gold-plated contact parts effectively reduces ultra-high-frequency signal transmission loss and contact resistance. The electromagnetic shielding performance meets military standard-level standards, reducing signal crosstalk and electromagnetic interference, and ensuring high-fidelity and distortion-free transmission of RF signals within 6GHz.

🟠 High adaptability and versatility, excellent compatibility: 50Ω standard RF impedance design, fully compatible with SMP series connectors of the same specification, and can be adapted to various RF cables such as RG086 and RG405, meeting the connection needs of different ultra-miniaturized and high-density RF equipment with strong versatility.

🟠 Precise and reliable craftsmanship, stable performance without attenuation: Adopting micron-level tolerance control and military standard-level surface treatment standards, the fitting gap between components is extremely small, and the structural stability is strong. It can effectively shield external strong electromagnetic interference, ensuring that the product has stable performance without attenuation during long-term continuous and high-intensity use, adapting to the high reliability requirements of high-end equipment.

Application Scenarios

🟠 Aerospace: Suitable for satellite communication RF components, airborne radar modules, aerospace measurement and control RF equipment, aviation micro communication terminals, etc. It meets the strict requirements of the aerospace field for ultra-miniaturization, high reliability and vibration impact resistance of equipment, and ensures stable transmission of high-frequency RF signals.

🟠 Microwave communication and radar systems: Applied to microwave communication base stations, phased array radar RF modules, satellite receiving/transmitting equipment, microwave relay communication equipment, etc., realizing efficient connection of high-frequency signals between high-density RF components, and adapting to the high-frequency and high-integration development needs of microwave communication and radar systems.

🟠 Test and measurement: As the RF signal interface of precision test instruments such as ultra-high-frequency oscilloscopes, microwave signal generators, RF vector network analyzers, and high-frequency test probes, it meets the ultra-high-frequency and high-precision signal testing needs of laboratories and high-end testing institutions.

🟠 Military electronics: Adapted to military communication equipment, portable military RF terminals, weapon system RF measurement and control modules, etc., it can withstand complex working conditions such as vibration, impact and extreme temperature in military scenarios, ensuring the high reliability of military RF systems.

🟠 High-end industrial electronics: Used in industrial microwave equipment, high-end radio frequency identification (RFID) readers, industrial automation high-density RF measurement and control terminals, precision semiconductor testing equipment, etc., adapting to the complex working conditions of high-end industrial sites and the needs of high-integration equipment.

🟠 High-end modules of communication equipment: Applied to 5G/6G micro base station high-density RF modules, optical fiber communication RF conversion components, high-end wireless communication terminal RF modules, etc., realizing stable connection of high-density and ultra-high-frequency signals in modules, and helping the miniaturization and high performance of communication equipment.

🟠 Transformation and upgrading projects: It can directly replace the SMP RF connectors of the same specification in old high-end RF equipment without changing the original structure of the equipment, quickly improve the high-frequency signal transmission performance and connection reliability of the equipment, and reduce the overall upgrading and transformation cost of high-end equipment.

Frequently Asked Questions (FAQ)

Q: What is the delivery time for customized SMP-KWB2 RF connectors?
A: The delivery time is usually 1 to 2 weeks, depending on the complexity of custom requirements (such as special surface treatment, non-standard dimensions) and the scale of the purchase order. The delivery date for bulk customization can be coordinated according to the production plan.

Q: What cable specifications does the SMP-KWB2 RF connector support, and can it be customized for adaptation?
A: The product is natively adapted to various RF cables such as RG405 and RG086; at the same time, it supports customization according to drawings according to customers' actual needs to meet personalized connection requirements.

Q: Compared with ordinary silicone rubber, what performance improvements does the fluororubber seal of the SMP-KWB2 RF connector have?
A: Compared with ordinary silicone rubber, the fluororubber seal has better high-temperature resistance, low-temperature resistance and chemical corrosion resistance. At the same time, it has a higher sealing protection level, and can be used in harsh chemical environments such as acid-base, oil pollution and high humidity, which greatly improves the protection capability and environmental adaptability of the product in complex industrial, military and aerospace scenarios.

Q: Does your company provide professional technical support and supporting services for the SMP-KWB2 RF connector?
A: We mainly supply high-performance RF connector products, and at the same time can provide professional technical support, including installation guidance, cable adaptation suggestions, on-site technical consultation, etc., to ensure the correct installation and stable use of the connector.

Contact Us

Are you ready to choose a more reliable connection solution for your RF system? Contact us today to get free technical consultation and exclusive customized quotation for the SMP-KWB2 RF connector. Our team of RF technical experts is ready to answer your questions and provide customized solutions that meet the needs of high-end RF applications.

E-mail: [email protected]
Tel: 86-18115599525
With precise connection, transmit stable signals —— The SMP-KWB2 RF connector guards your RF system!
