Product Introduction of SMC-C-K1.5 RF Connector

Specifications and Parameters

Core Materials

🟠 Contact parts: High-purity brass (gold-plated), improving electrical conductivity, corrosion resistance and oxidation resistance.

🟠 Insulators: Polytetrafluoroethylene (PTFE), high temperature resistant, low dielectric loss, suitable for high-frequency miniaturized signal transmission.

🟠 Housing/structural parts: High-quality brass (HPB59-1), nickel-plated, enhancing structural strength and wear resistance, suitable for miniaturized plug-in working conditions.

🟠 Seals: High-performance silicone rubber, improving IP protection level, suitable for complex environments such as high dust and high humidity.

Electrical Performance

Product Features

🟠 Ultra-miniature design, suitable for miniaturized scenarios: Adopting SMC standard ultra-miniature structure, its volume perfectly fits space-constrained application scenarios such as portable RF equipment, micro RF modules, and automotive miniaturized RF terminals, without affecting the overall layout of the equipment.

🟠 High-frequency and low-loss, high-fidelity signal transmission: Precision impedance matching design combined with gold-plated high-purity contact parts effectively reduces high-frequency signal transmission loss and contact resistance, with excellent electromagnetic shielding performance. It can ensure high-fidelity transmission of RF signals within 6GHz, meeting the strict requirements of high-precision testing, high-frequency wireless communication and other scenarios.

🟠 Ultra-long mechanical life, outstanding durability: The housing and structural parts adopt brass nickel-plating process, and the contact parts are gold-plated, with excellent corrosion resistance, wear resistance and fatigue resistance. It can withstand more than 1,000 insertions and extractions and long-term vibration conditions, extending the service life of the product and reducing the frequency of later equipment replacement and maintenance.

🟠 Wide temperature and weather resistance, suitable for various complex environments: It can work stably in the extreme temperature range of -45℃ to +125℃, with excellent vibration resistance, salt spray resistance and moisture resistance. It is suitable for harsh service environments such as automotive interior/exterior, outdoor micro base stations, industrial precision measurement and control, and aerospace supporting facilities.

🟠 High adaptability and versatility, strong compatibility: 50Ω standard RF impedance design, fully compatible with SMC series connectors of the same specification, and can be adapted to various RF cables such as RG316 and RG174, meeting the connection needs of different miniaturized RF equipment with strong versatility.

🟠 Precise craftsmanship, stable performance without attenuation: Strict micron-level tolerance control and high-standard surface treatment, the fitting gap between components is extremely small, and the structural stability is strong. It can effectively shield external electromagnetic interference and signal crosstalk, ensuring stable performance of the product without attenuation during long-term continuous use.
Application Scenarios

🟠 Wireless communication: Applied to micro wireless base stations, portable wireless communication terminals, Bluetooth/RF modules, private network communication micro equipment, etc., realizing efficient signal connection between miniaturized RF equipment and adapting to the miniaturization development needs of mobile communication and private network communication.

🟠 Test and measurement: As the RF signal interface of precision test instruments such as portable oscilloscopes, micro signal generators, handheld spectrum analyzers, and RF test probes, it meets the high-precision, miniaturized signal testing needs of laboratories and on-site detection.

🟠 Automotive electronics: Adapted to automotive radar, vehicle-mounted wireless communication modules, vehicle-mounted navigation RF terminals, new energy vehicle on-board measurement and control RF equipment, etc., it can withstand vibration and high-low temperature changes in the automotive environment, ensuring stable vehicle-mounted RF signals.

🟠 Industrial electronics: Used in industrial automation micro RF measurement and control equipment, radio frequency identification (RFID) small readers, industrial microwave micro modules, portable industrial detection equipment, etc., adapting to the complex working conditions of industrial sites.

🟠 Consumer electronics: Applied to consumer-grade miniaturized RF products such as portable RF detection equipment, handheld wireless terminals, and micro RF transmitting/receiving modules, meeting the lightweight and miniaturized design needs of consumer electronics.

Frequently Asked Questions (FAQ)

Q: What is the delivery time for customized SMC-C-K1.5 RF connectors?
A: The delivery time is usually 1 to 2 weeks, depending on the complexity of custom requirements (such as special surface treatment, non-standard dimensions) and the scale of the purchase order. The delivery date for bulk customization can be coordinated according to the production plan.

Q: What cable specifications does the SMC-C-K1.5 RF connector support, and can customized cable adaptation solutions be provided?
A: The product is natively adapted to various micro RF cables such as RG316, RG174, and RG179; at the same time, it supports customization according to drawings according to customers' actual needs to meet personalized connection requirements.

Q: Does your company provide technical support and installation guidance for the SMC-C-K1.5 RF connector?
A: We mainly supply high-performance RF connector products, and at the same time can provide professional technical support, including installation guidance, cable adaptation suggestions, on-site technical consultation, etc., to ensure the correct installation and stable use of the connector.

Contact Us

Are you ready to choose a more reliable connection solution for your RF system? Contact us today to get free technical consultation and exclusive customized quotation for the SMC-C-K1.5 RF connector. Our team will be ready to answer your questions and provide RF connection solutions that fit your actual needs.

E-mail: [email protected]
Tel: 86-18115599525
With micro precision connection, transmit high-frequency stable signals —— The SMC-C-K1.5 RF connector guards your RF system!
